JSRLF SeRieS Low FLow PReSSuRe Reducing VaLVe
orDering schematic
Model Size Material
/
1 & 2 3 & 4 5 & 6 7 & 8 9 & 10 11 & 12 13 & 14 15 16 17
— —
Model
JSRLF Low Flow Pressure Reducing Valve
Size
025 1/4" (DN08)
038 3/8" (DN10)
050 1/2" (DN15)
Material
6L ASTM A479, 316L
1 & 2
Body Feature
End Connection Port Conguration
A FNPT, 1/4" A Port "A"
B FNPT, 3/8" B Port "B"
C FNPT, 1/2" C Port "C"
T ASME BPE Tri-Clamp, 1/2" D Port "D"
W ASME BPE Tube Weld, 1/2" E Port "E"
S
1
ISO Tri-Clamp, DN15
D
2
DIN Tri-Clamp, DN15
M
3
DIN Tube Weld, DN15
P
4
ISO Tube Weld, DN15
ZZ Non-Standard
1
Acc. to DIN 32676 Row B (ISO 1127). See dimensions, page 3
2
Acc. to DIN 32676 Row A (DIN 11850). See dimensions, page 3
3
Acc. to DIN 11866, DIN 11850 Row A
4
Acc. to DIN 11866 Row B, (ISO 1127)
3 & 4 Trim
1S Cv 0.012
2S Cv 0.08
3S Cv 0.2
4S Cv 0.03
1R Cv 0.012 Self-Relieving
2R Cv 0.08 Self-Relieving
3R Cv 0.2 Self-Relieving
4R CV 0.03 Self-Relieving
ZZ Non-Standard
5 & 6 Seat Material - FDA & USP Class VI
T1 PTFE Cv 0.012 P2 PEEK Cv 0.08
T2 PTFE Cv 0.08 P3 PEEK Cv 0.2
T3 PTFE Cv 0.2 P4 PEEK Cv 0.03
T4 PTFE Cv 0.03
ZZ Non-Standard
P1 PEEK Cv 0.012
7 & 8 Range Spring / Outlet Pressure
E1 5 - 50 psi E5 100 - 450 psi
E2 25 - 100 psi
E6
200 - 750 psi
(NPT only)
E3 50 - 150 psi
E4 75 - 250 psi ZZ Non-Standard
9 & 10 Diaphragm Material
JL Jorlon
TM
PTFE, FDA & USP Class VI
ZZ Non-Standard
11 & 12 Actuator
SK Standard Actuator
AK
Autoclavable Anodized Aluminum Knob available
as cataloged option
CV Captured Vent
PM Panel Mount
TP Anti-tamper feature (See illustration page 3)
ZZ Non-Standard
13 & 14 Inlet Gauge
AA
0 - 30 psi / bar
(Dual)
HH
0 - 600 psig/bar (Dual)
NPT only
BB
0 - 60 psig / bar
(Dual)
JJ
0 - 1000 psi/bar (Dual)
NPT only
CC
0 - 100 psig / bar
(Dual)
KK
0 - 2000 psi/bar (Dual)
NPT only
DD
0 - 160 psig / bar
(Dual)
LL
0 - 3000 psi/bar (Dual)
NPT only
EE
0 - 200 psig / bar
(Dual)
MM
0 - 5000 psi/bar (Dual)
NPT only
FF
0 - 300 psig / bar
(Dual)
NN None
GG
0 - 400 psig / bar
(Dual)
ZZ Non-Standard
15 Outlet Gauge
A 0 - 30 psig
B 0 - 60 psig / bar (Dual)
C 0 - 100 psig / bar (Dual)
D 0 - 160 psig / bar (Dual)
E 0 - 200 psig / bar (Dual)
F 0 - 300 psig / bar (Dual)
G 0 - 400 psig / bar (Dual)
H 0 - 600 psig / bar (Dual) NPT only
J 0 - 1000 psi / bar (Dual) NPT only
N None
Z Non-Standard
16 SEP Compliance
G SEP Compliant
Ø None
Z Non-Standard
17 Accessories
S Clean For Oil Free
X Clean For Oxygen
Ø None
Z Non-Standard
