JSRLF SeRieS Low FLow PReSSuRe Reducing VaLVe
Features & BeneFits
-4-
Fine thread pitch for precision
setpoint adjustments.
ASTM A479 316L body
and bonnet material
ASME BPE SF5, 20 Ra µin
(0,5 Ra µm) electropolish
finish is standard
FDA / USP Class VI seat
material for ANSI Class VI
shutoff
Sanitary clamp, tube
and weld, or threaded
connections 1/4", 3/8", 1/2"
Optimal internal
volume
PTFE-Jorlon
TM
FDA / USP Class VI approved
Unsurpassed life
Flow conFigurations
outlet inlet
outlet gage
inlet gage
* Gage ports are 1/4" FNPT (consult factory for required alternative)
Consult factory for other porting options
A B
D E
outlet inlet
outlet inlet outlet inlet
inlet gage
outlet gage
outlet gage
outlet inlet
SAMPLE
C
outlet inlet
270°
90°
Autoclavable Anodized Aluminum
Knob available as cataloged option
