2-Stroke Auger SP-GMK049 12/2012
CONTENTS Preface Safety Precautions Warning Labels Safety Precautions Main Specifications Assembly 1.) Opening The Box 2.) Assembly 3.
PREFACE Dear users: Thank you for purchasing our Auger. Before using, please read this manual carefully to know well about the machine’s performance, so you can operate this machine safely and correctly. Please keep this manual handy so you can refer to it later. Always be sure to include this manual when transporting this machine. There may be upgrades to the specifications of this machine which may or may not differ slightly from this manual. Please read and understand this manual.
REFERENCE A B C A f D a b c d e E f 1 3 2 4 A A D B f B Nut Screw 5 A 6 D C d Nut Screw 2 e
REFERENCE 7 H G F A I J B D C Screw Screw Nut Gear Box Big Washer Shock Absorber Pad E Link Plank Gear Box Big Washer Screw A. Engine Assembly C. Left Handle Bracket E. Drill Bit G. Fuel Tank Lid Comp I. Stop Button Comp a. Alley Key S=6mm c. Box Spanner 17X19 e. Open Spanner 13X16 B. Gear Box Assembly D. Right Handle Bracket F. Fuel Tank H. Starter J. Throttle Trigger b. Alley Key S=5mm d. Open Spanner 10X13 f.
REFERENCE Screw a a E E 8 9 K G F 10 12 11 13 L 4
REFERENCE CLOSE START STOP OPEN I J 14 16 15 18 M 17 H K. Fuel Mixture Bottle L. Oil Pumping Device M. Choke Lever N.
REFERENCE 19 20 P Q P Q S R 21 23 22 24 GREASE S U OIL T 6
REFERENCE 19 20 P Q P Q 25 26 27 S R P. Air Filter Cartridge Q. Outside Cleaner Cover GREASE R. Fuel Filter S. Spark Plug T. Screw U. Spark Plug Cap V. Inserted Drill W. Hard Alloy Blade T X. Carbide Blade Y. Stainless Steel Blade Z.
SAFETY PRECAUTIONS Warning! If used correctly, this Auger is a powerful, fast, high performance tool. If used improperly or without due precautions it could become a dangerous tool. Always comply with the safety rules and regulations throughout this manual. It is important that you read, fully understand and observe the following safety precautions and warnings. Careless or improper use of this machine may cause serious or fatal injury.
(3) Never wear scarves, bracelets or anything else which could get caught in the machine or bit. Wear close-fitting safety clothing. (4) Wear protective non-slip safety shoes, gloves, glasses, ear protection and a safety helmet. (5) Do not allow people near the machine while in use. (6) Do not start working until you have a clear work area. Do not work near electric wires or cables.
(20) Store the power drill off the ground, in a vertical position and in a dry place. Make sure the fuel tank is empty. (21) Check the power drill each day to ensure that each component is functional. (22) While working and moving from one work area to another make sure the engine is on the idle position. (23) Never use a damaged, modified, or improperly repaired or assembled power drill. Do not remove or dis-activate any of the safety features. Only use bits that are specifically made for this machine.
SPECIFICATIONS Name Model Power drill AG43J SP-GMK049 Dimensions(LxWxH) Power Drill TAG52N 1240x280x280 Weight 14kg 15kg Reduction ratio 40:1 Speed-change Type Double-reduction Transmission Mode Centrufugal friction clutch Drill_Bits _6/_8/_10/_12/_15cm Type _6/_8/_10/_12/_15/_20cm Single Operated unit Type Engine AG52J Air-cooled Two stroke engine Model 1E40F-5A 1E40FN 1E44FA 1E44FN Power 1.25kW /6500r/min 1.3kW /7500r/min 1.46Kw /6500r/min 1.
ASSEMBLY 1.) Open the box Remove the machine from the box, check the machine for damage, and make sure all the components are complete. (Fig.1) Page 2 . 2.) Assemble the machine a.) Rotate the machine by 90 degrees like (Fig.2), the air filter cover would be on the top side, use the accessory box to put under the gear case like (Fig.3) Page 2. b.) Remove the four Bolts M8X25,and the NUTs M8 as per (Fig.3) Page 2. c.) Assemble the right control handle on the connect plate from the right side.(Fig. 4) Page 2.
STARTING 1. Fuel Mixture Use a 2% or 4% (50:1 or 25:1) oil/gasoline mixture (Fig.10) (Please use fuel mixture of 25:1(gasoline:oil) 20 hours before the the machine runs.) Warning!2-stroke engines have high specific horsepower and we recommend the use of regular or super unleaded gasoline, with or without lead and an octane rating of no less than 90. When preparing the mixture, only use oil for two stroke engines. Shake the fuel mixture container before filling the tank. (Fig.11) Page 4.
Note Do not use the choke (M , Fig.15. Fig.16) Page 5 when starting a hot engine. When the engine is idling, the bit should not turn. Warning! If the bit jams, stop the engine immediately. Note When pulling the pull start a) Do not let the starter grip snap back b) Do not pull the starter rope out all the way as it might break. (N ,Fig.17) c) Guide it slowly back into the housing so that the starter rope can rewind properly. STOPPING THE ENGINE a) Bring the throttle to the idle position (J,Fig.
ENGINE-Clean the cylinder fins with compressed air or a brush periodically. Overheating of engine may occur due to impurities in the cylinder. SPARK PLUG-Remove the spark plug cover, unscrew the spark plug. Clean the spark plug if carbon deposits are found. Polish the electrode with abrasive paper and adjust the electrode gap to 0.6-0.7mm (Fig.22) Page 6. BIT-Always check the drill bit. Sharpen or replace it if necessary. Check and repair the blade (X,Fig.26) regularly.
TROUBLESHOOTING GUIDE 1) Starting Failure Trouble Sparking (no spark) Spark plug Causes 1.Spark plug is wet 2.Carbon deposit in the spark plug 3.The plug gap is too big or too small 4.The electrode burned out 5.Insulation damage Magneto Causes 1.Wiress damaged or broken 2.The insulation of coil is bad 3.The gap between stator and rotor is too big Trouble The spark plug works normal Compression is good and fuel is normal Causes 1.Excessive fuel usage 2.
TROUBLESHOOTING GUIDE 2) Lack of Power Trouble The compression is fine and has spark Causes 1.Air in the fuel valve 2.Air leak in carburetor connection 3.Fuel mixed with water 4.The filter plate is clogged 5.Muffler clogged Trouble Engine overheats Causes 1.Fuel is too thin 2.Cylinder is covered with carbon Trouble Engine is noisy or knocking Causes 1. Bad Fuel 2. Combustion chamber dirty 3.
TROUBLESHOOTING GUIDE Trouble The engine shuts down slowly Causes 1.Lack of fuel 2.Carburetor clogged 3.Water in fuel Fix Fill the tank Clean Refill with fresh fuel 4) Engine hard to stop Trouble Engine Causes Cylinder and piston overheat Trouble Bad circuit Causes 1.Plug pole overheats 2.Stop button is bad Fix Clean carbon Fix Clean plug & check gap Check and or replace 5) Other Trouble Engine works but bit does not turn Causes 1. Clutch damaged 2.
WARRANTY Limited Warranty The manufacturer, acting through the sales and technical assistance network, shall replace free of charge any parts proven defective in material, machining or manufacturing in a period of 2 years from the date of purchase. The warranty does not affect the purchaser’s right as established under legislation governing the consequences of defects in the machine. The warranty period starts on the date of purchase.
Part List 20
GENERAL PARTS 51010100047 70080070035 2020050014 70070080035 3060010004 3090010012 3120020004 3120010005 80020030001 70070080036 3090010034 80020030002 3090010009 3100010004 70070080037 3010010033 3010010046 3010110037 3010010011 3010010013 2080020122 70080120163 2050050310 3020020038 3060030009 70030070084 70030070145 1040030001 2050040173 3120030003 3030070008 2020110114 2050210043 2500010006 2080010027 2020160656 3010070019 3030050010 3010110038 2110030022 3010010081 2020080044 2020070019 2020080009 2020
22
3020010014 3040050022 70030030717 3130010013 2020160191 3010010062 70070130003 2070010021 2020020009 2010020015 3090020009 2020150001 2020010011 2020030014 3070010001 3060010004 3090010037 70070050005 3100010024 3010010071 2050030003 3030010017 3050010008 3040020018 3040050048 2050160006 3040050043 2020130003 70070030003 3020030016 2050120002 2080030025 61330010010 2110020026 70050030141 3040010010 2070010079 2080030016 2020160265 70030020014 3030070015 2020160426 3010010058 2020160250 70030040044 205002003
2090010014 3020020031 70030040071 70030070026 2020120068 2070010111 70070050006 3100010025 2050100010 2050070004 3010110130 3020020029 2050050137 2050030004 2070010137 2050010047 3040020015 3050010012 3010010036 70030030719 1-53 1-54 1-55 1-56 1-57 1-58 1-59 1-60 1-61 1-62 1-63 1-64 1-65 1-66 1-67 1-68 1-69 1-70 1-71 1-72 AIR FILTER ELEMENT BOLT ASSY (M5X60) COVER, CLEANER KNOB, COVER CRANK SHAFT ASSY GASKET, CRANKCASE REAR CRANKCASE OIL SEAL (12X28X7) STARTER PULLEY COMP STARTER COMP SCREW (M5X16) SCREW
