4. While firmly holding onto edge of reel drum, unlatch reel and carefully allow drum to
slowly rewind, drawing hose end back through guide arm roller assembly and onto reel.
5. To increase tension: Unlatch reel and turn clockwise (as viewed from air inlet side).
To decrease tension: unlatch and allow reel to rotate slowly counterclockwise (as
viewed from air inlet side).
6. Once desired spring tension is reached latch reel in position. Feed hose end through
roller assembly in guide arm and re-attach hose stopper.
7. Connect incoming air supply.
REPLACING AIR INLET VALVE O-RINGS
1. Disconnect incoming air supply and inlet-end of hose from brass air inlet valve.
2. Unscrew air inlet valve assembly (parts 6a and 6b) from axle shaft (part 13) fitting
wrench onto hex portion of valve and turning counterclockwise.
4. Remove retaining ring (part 31) and slide air inlet valve swivel collar (part 6b) off
from air inlet valve body (part 6a).
5. Remove worn O-rings (2 pcs) and replace with new parts.
6. Reverse above procedure to re-assemble.
REPLACING HSOE
1. Secure and stabilize reel. In most cases, hose can be replaced with reel still mounted.
2. Disconnect incoming air supply.
3. Pull out entire length of hose and lock reel. Mask sure reel is securely locked in place.
4. Unscrew hose clamps that secure hose to drum. Disconnect inlet-end of hose from air
inlet valve.
5. Pull inlet-end of hose through slot in drum and guide rollers, removing old hose completely.
6. Remove spring hose guard, hose clamp and hose stopper from old hose. Fit these parts
on new hose in identical positions.
7. feed inlet-end of hose through guide rollers and slot in drum .
8. Apply teflon sealant tape or thread sealant to hose connector and connect to air inlet valve.
9. Attach hose clamp to drum. Rewind hose onto reel using normal operation.
REPLACING SPRING CANISTER
1. Follow steps 1-4 under “Adjusting Recoil Tension” above.
2. Unlatch reel and allow drum to slowly rewind completely until tension spring is relieved
and reel stops. Carefully control speed of drum - do not release while rewinding.
4. Remove air inlet valve and spacing washer. Refer to “Replacing air inlet valve O-rings:
step 2”,
5. Remove nuts from mounting bracket-side of drum, inside drum cavity. Do not attempt
to remove spring canister nuts on air inlet-side of drum.
6. Pull entire spring canister (part 1) off drum axle (part 13), Replace with new spring canister.
7. Reverse above procedure to re-assemble.
8. After assembly, re-tension the reel by turning the drum three complete turns clockwise
(as viewed from air inlet side) and latch reel.
9. Feed hose through guide arm and re-attach hose stopper.
