EA-AMP-SUB-1D-110 Installation and Users Manual
pg.7
Continuous Power Output 68 watts RMS at 8 ohms
110 watts RMS at 4 ohms
Input Sensitivity 195 mv for full output, 110 watts, with level control set to max.
Frequency Response 35 - 200 Hz
Distortion .10% THD+N 1W/2W 100 Hz
Auto On Sensitivity 3.5 mv
External Trigger Voltage 9.5 V - 20 V
Dimensions 16.9˝ W (18.9˝ including rack mounts)
1.75˝ H (1.9˝ including feet)
8.5˝ D (knob to rear chassis) 9.3” D (knob to rear speaker connector)
Weight 19.7 lbs.
Certication ETL Listed and tested under UL/EN60065 for US and Canada
No audio output
• Power cable to the amplier is incorrectly connected or plugged
into an outlet that does not have power. Check connections and
verify power at the outlet.
• Audio cable to the source component is not connected properly,
connected to output or the cable is defective. Check connections
or replace cable with one that has been veried as good.
• Amplier is in standby mode, and needs to be turned on “BLUE LED”.
• Check the connections of the speaker wire at both the speaker and amplier.
• The level adjustment is turned down. Turn it to the right slowly to
raise the volume.
Hum or buzzing
sound is heard
• Check RCA input cables by removing them one at a time (powering
down the amplier before disconnecting) and verify connections.
Amplier will
not turn on
• The amplier must be plugged into a live outlet.
• The Power Switch on the front panel must be on.
• The Power Mode switch may be set to the wrong mode for your system.
SPECIFICATIONS
TROUBLE SHOOTING
This amplier is designed to function trouble-free. Most problems that occur are due to simple issues.
If you have trouble, check the list of simple xes below. If the problem persists, contact your authorized
Episode dealer or Episode technical support at 866-838-5052.
WARRANTY
2-Year Limited Warranty
Episode™ Amplier Products have a 2-Year Limited Warranty. This warranty includes parts and labor repairs on all
components found to be defective in material or workmanship under normal conditions of use. This warranty shall
not apply to products which have been abused, modied or disassembled. Products to be repaired under this warranty
must be returned to the SnapAV or a designated service center with prior notication and an assigned return
authorization number (RA).
