User Guide

Technical Specifications
Warranty 2 Years
Audio Yes
Output Signal DisplayPort
Maximum Data
Transfer Rate
40 Gbps
Maximum Digital
Resolutions
Dual monitor: 4K @ 60 Hz
Supported
Resolutions
4096x2160
3840x2160
2560x1600
1920x1200
1920x1080
1280x720
Note: The adapter can support 5120×2880 (5K) when both DP outputs are connected to
single monitor that supports 5K
Connector A 1 - Thunderbolt™ 3 USB-C (24-pin) Male Input
Connector B 2 - DisplayPort (20 pin) Latching Female Output
OS Compatibility Microsoft Windows® 10, 8/8.1
Product Height 1 in [26 mm]
Product Length 8.7 in [220 mm]
Product Weight 17.6 oz [500 g]
Product Width 3.1 in [80 mm]
Shipping (Package)
Weight
0.4 lb [0.2 kg]
Included in Package 1 - Thunderbolt 3 to dual DP adapter
Type and Rate Thunderbolt 3 - 40 Gbit/s
www.startech.com
1 800 265 1844
