Technical Specifications
Warranty Lifetime
Bus Type USB 2.0
Chipset ID FTDI - FT232RL
Industry Standards RS232
Industry Standards USB 1.1
Interface Serial
Port Style External Hub
Ports 4
FIFO 256 Bytes
Max Baud Rate 921.6 Kbps
Serial Protocol RS-232
Connector Type(s) 1 - USB A (4 pin) Male
External Ports 4 - DB-9 (9 pin; D-Sub) Male
OS Compatibility Windows® 8 / 8.1 (32/64bit), 7 (32/64), Vista (32/64), XP (32/64), 2000, 98SE, XP
Embedded, CE (4.2+)
Windows Server® 2012, 2008 R2, 2003
Mac OS® 10.x (Tested up to 10.10)
Linux 2.4.x / 2.6.x
System and Cable
Requirements
One free USB port
Cable Length 6 ft [1.8 m]
Enclosure Type Plastic
Product Height 1 in [26 mm]
Product Length 5.9 in [150 mm]
Product Weight 3.9 oz [110 g]
Product Width 2.6 in [66.5 mm]
Power Consumption 1 ~ 1.5W
Humidity 5~95% RH
Operating Temperature 0°C to 55°C (32°F to 131°F)
Storage Temperature -20 to 85°C (-4 to 185°F)
Shipping (Package)
Weight
0.8 lb [0.4 kg]
Included in Package 1 - 4 Port Serial Hub
Included in Package 1 - USB Cable
