Specications
Interface
USB 3.0 base specication 1.0
Intel xHCI specication 0.95
Host Interface ExpressCard 2.0
Form Factor ExpressCard/54 (54mm)
Chipset ID NEC uPD720200
External Connectors
2 x USB 3.0 type A female
1 x DC Power
LEDs N/A
Power Adapter (Optional) 5VDC, center positive, type A plug
Maximum Data Transfer Rate USB 3.0: 5 Gbps
Operating Temperature 0°C ~ 85°C (32°F ~ 185°F)
Storage Temperature -65°C ~ 125°C (-85°F ~ 257°F)
Dimensions 74.0mm x 54.0mm x 5.0mm
Weight 23.8g
Compatible Operating Systems
Windows 2000/XP/Server 2003/Vista/
Server 2008 R2/7 (32/64-bit)
* If used with ExpressCard 1.0 enabled computer systems, the max throughput is
limited to 2.5 Gbps. If used with ExpressCard 2.0 enabled computer systems, the max
throughput is 5 Gbps.
