Specications
Host Interface USB 3.0
Chipset
DisplayLink - DL-3900
Genesys - GL3520
Realtek - RTL8211E
Connectors
2 x 3.5 mm Mini-Jack (3 Position) Female
1 x DVI-D (25 pin) Female
1 x HDMI (19 pin) Female
1 x RJ-45 Female
1 x VGA (15 pin; High Density D-Sub)
3 x USB 3.0 type A Female
1 x USB 3.0 type B Female
Maximum Data Transfer Rate
USB 3.0: 5 Gbps
LAN: 2 Gbps (Full-Duplex)
Supported Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, USB 3.0
Supported Network Link Speeds 10/ 100/ 1000 Mbps
Ethernet Full Duplex Support Yes
Auto MDIX Yes
Maximum Video Resolution
2048 x 1152 (VGA)
1920x1200 (DVI-D)
1920x1080 (HDMI)
Audio Support Yes (2-Channel Stereo, Mic)
Power Adapter 5V DC, 4000mA, Center Positive
Enclosure Material Plastic
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -10°C to 60°C (14°F to 140°F)
Dimensions 263 x 87 x 34 mm
Weight 289g
Compatible Operating Systems
Windows® 8 / 8.1 (32/64bit), 7 (32/64), Vista
(32/64), XP SP3 (32), Mac OS® 10.6 and up
(Tested up to 10.9)
