Supported Video Resolutions
Resolution Refresh Rate
640 x 480 60/ 72/ 75/ 85 Hz
800 x 600 56/ 60/ 72/ 75/ 85 Hz
1024 x 768 60/ 70/ 75/ 85 Hz
1280 x 720 60 Hz
1280 x 768 60/ 75/ 85 Hz
1280 x 800 60 Hz
1280 x 1024 60/ 75 Hz
1366 x 768 60 Hz
1400 x 1050 60/ 75/ 85 Hz
1600 x 1200 60 Hz
1680 x 1050 60 Hz
1920 x 1080 60 Hz
1920 x 1200 60 Hz
2048 x 1152 60 Hz
Inferred Modes
Some modes in the DisplayLink GUI are shown with
[ ] around them. This occurs when connecting a
monitor with a preferred mode (native resolution)
higher than the maximum supported resolution of
the DisplayLink device. In cases where the preferred
resolution of the monitor cannot be supported,
lower resolutions of the same aspect ratio are
suggested in brackets. As these are inferred modes
from the preferred mode of the monitor, they are
not guaranteed to work with the display.
