Introduction
Packaging Contents
• 1x Dual Rail Rack Console
• 1x Set, Mounting Rails
• 2x USB A to A Cables
• 1x DVI Cable
• 1x VGA PS/2 KVM Cable
• 6x 6mm Flat Screws
• 2x Keys
• 2x Blockers w/ screws
• 1x NA Power Cord
• 1x Power Adapter
• 1x Instruction Manual / Software CD
Front Panel Controls
Controls Description
Soft power on/o button. Adjacent LCD is lit when on.
Auto
Auto-synchronize and scale down display to any valid
factory preset timings.
Up Press to scroll the function you want to adjust.
Down Press to scroll the function you want to adjust.
Menu
To access the main menu. This button also acts as
the “Enter” button.
Power Indicator
GREEN
RED
RED
RED
ON
STANDBY
SUSPEND
OFF
