Specications
Display Size 17.3”
Panel Type Active Matrix TFT LED
Maximum Screen Resolution 1920x1080 (Full HD)
Supported Platforms USB or PS/2
Server / KVM Video Type DVI or VGA
Response Time 2ms
Contrast Ratio 650:1
Brightness 300cd/m²
Viewing Angle 140° (H), 120° (V)
Pixel Pitch 0.264 x 0.264 mm
Keyboard/Mouse 106-key USB keyboard with touchpad
Console Interface(s)
2x PS/2 (6 pin; Mini-DIN)
1x VGA (15 pin; High Density D-Sub)
1x DVI (29 pin)
2x USB A (4 pin)
Other Interface(s) 2x USB A (4 pin)
Chassis Material Heavy-duty steel
Minimum/Maximum Mounting
Depth
22.4 x 34.2 inches (570 – 870 mm)
Power Supply 100~240V AC Input
Power Consumption 10.2W
Operating Temperature 0°C to 50°C (32°F to 122°F)
Storage Temperature -20°C to 60°C (-4°F to 140°F)
Humidity 10~90% RH
Dimensions (LxWxH) 21.2 x 17.6 x 1.7 inches (540 x 448 x 44 mm)
Weight 28.7 lbs (13 kg)
