U 17in 1080p Dual Rail LCD Rack Console with Front USB Hub RACKCOND17HD RKCOND17HDGB *actual product may vary from photos DE: Bedienungsanleitung - de.startech.com FR: Guide de l'utilisateur - fr.startech.com ES: Guía del usuario - es.startech.com IT: Guida per l'uso - it.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com For the most up-to-date information, please visit: www.startech.
FCC Compliance Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
Table of Contents Product Diagram.....................................................................................1 Front View..................................................................................................................................................... 1 Rear View....................................................................................................................................................... 1 Introduction......................................................
Product Diagram Front View Top Handle Key Lock Menu Buttons Fingerprint Reader Keyboard Tray Handle USB 2.0 Hub Ports Power Switch Top Handle Hidden Keyboard Tray Handle USB 2.
Introduction Packaging Contents • 1x Dual Rail Rack Console • 1x Set, Mounting Rails • 2x USB A to A Cables • 1x DVI Cable • 1x VGA PS/2 KVM Cable • 6x 6mm Flat Screws • 2x Keys • 2x Blockers w/ screws • 1x NA Power Cord • 1x Power Adapter • 1x Instruction Manual / Software CD Front Panel Controls Controls Description Soft power on/off button. Adjacent LCD is lit when on. Auto Auto-synchronize and scale down display to any valid factory preset timings.
Installation Rack Installation NOTE: The cabinet depth must be within 22.4 – 34.2” (570 - 870 mm). 1. Adjust rail with rear bracket to fit your rack. 2. Secure the front and rear brackets onto the rack using screws and cage nuts appropriate to your rack (not included). 3. Repeat steps 1-2 for the other side.
4. Slide the console into the rails and leave about 5-10cm of space to install the blockers. 5. Install one of the Blockers onto the back of the console as shown, and use the included screw to secure it. Repeat on the other side.
6. Install three of the included 6mm Flat Screws to secure the console to the bracket. Repeat on the other side to complete the installation. PC / Server Connection 1. Turn off the PC / Server you are connecting to the console. 2. Using one of the included cable sets, connect the appropriate video (VGA / DVI) connector to the video output of your PC / Server. Then connect either the PS/2 keyboard/mouse connectors, or use the USB interface. 3. Connect the other end of the cables to the rear of the console.
Operation 1. Once all cables are securely connected and all mounting screws are properly tightened, loosen the thumbscrews on the front of the console. 2. Grasp the Top Handle and pull the console outward and then lift upward to open. 3. Turn the Power Switch on the front of the console to the On position, and power on the connected Server or KVM switch. NOTE: There is also a soft Power On/Off button located with the menu controls below the LCD panel.
Dual Rail Slide The dual-rail console design allows the LCD display and keyboard/mouse to slide independently from the keyboard/touchpad tray. 1. With the console lid open (keyboard tray can be in the rack or pulled out), grab both sides of the LCD panel at the bottom and pull towards you to slide the LCD forward. 2. You can then disengage the locks on the keyboard tray rails to slide the console back into the rack if desired, leaving the LCD panel visible.
Fingerprint Reader Once installed, the fingerprint reader software offers several options to configure biometric access, application / file launching and virtual secure storage drives. Windows 1. Insert the included CD and navigate to your CD/DVD drive to install the included fingerprint reader application. The software will create an icon in your system tray. NOTE: You may be prompted to restart after the install 2. Open the software to view the main menu window.
Password Bank Management – Manages passwords for both websites and applications. Finger Launch Management – Configures application or file launch at the swipe of a finger. Data Protection: Change Default Password – Create or change a default password for data encryption. Yo-Safe Management – Create and manage a secure virtual disk.
Advance Settings: BioExcess™ Functions Settings – Enable or disable Fast User Switching for all accounts. Data Backup – Backup enrolled fingerprints and Password Bank items. Data Restore – Restore backed up data from a file.
Specifications Display Size 17.3” Panel Type Active Matrix TFT LED Maximum Screen Resolution 1920x1080 (Full HD) Supported Platforms USB or PS/2 Server / KVM Video Type DVI or VGA Response Time 2ms Contrast Ratio 650:1 Brightness 300cd/m² Viewing Angle 140° (H), 120° (V) Pixel Pitch 0.264 x 0.
Technical Support StarTech.com’s lifetime technical support is an integral part of our commitment to provide industry-leading solutions. If you ever need help with your product, visit www.startech.com/support and access our comprehensive selection of online tools, documentation, and downloads. For the latest drivers/software, please visit www.startech.com/downloads Warranty Information This product is backed by a two year warranty. In addition, StarTech.
