Quick Start Guide

Instruction manual
11
Attach the base
1. Turn over the assembled pneumatic arm and line up the four holes on the
pneumatic arm (1) with the four holes on the base (6).
2. Use the M4*55 Allen wrench (13) to insert four M6*25 screws (16) through the holes
on the pneumatic arm (1) and into the base (6).
3. Turn the Allen wrench clockwise to tighten the screws.
13
16
6
