QUICK START GUIDE FOR

BABY MONITOR

Model Name：ABM1111/ABM1112 Client：Delta

1. Packing List

a) One BU (BABY) Transmitter

b) One PU (PARENT) Receiver

c) 2 AC adapters（5V/550mA )

d) Battery AAA x3（AAA alkaline batteries 3PCS, not included)

e) User manual (not with it at the moment)

2. Overview of product

2.1．PU（PARENT）

2.2．BU（BABY）

3. Start to use

①MIC

②Power button

③Power

Indicator

④ DC IN

⑩DC IN

①Speaker

②Volume down

③Power button

⑤Volume up

⑥ Communication

Indicator

⑦Power Indicator

⑧Belt clip

⑨Battery cover

④Volume Indicator

Summary of content (3 pages)

PAGE 1
QUICK START GUIDE FOR BABY MONITOR Model Name：ABM1111/ABM1112 Client：Delta 1. Packing List a) One BU (BABY) Transmitter b) One PU (PARENT) Receiver c) 2 AC adapters（5V/550mA ) d) Battery AAA x3（AAA alkaline batteries 3PCS, not included) e) User manual (not with it at the moment) 2. Overview of product 2.1．PU（PARENT） ①Speaker ②Volume down ③Power button ⑧Belt clip ④Volume Indicator ⑤Volume up ⑥ Communication Indicator ⑨Battery cover ⑦Power Indicator 2.
PAGE 2
3.1. PU receiver instructions Disassemble the battery cover screws by screwdriver. Insert three AAA alkaline batteries (Ensure the polarity of the batteries is right). Assemble the battery cover and fixed with screws. Note: Use battery or AC adapter as power supply. a Press the power button, power LED flashes green when powered by battery or power LED light on when powered by AC adaptor. b When battery voltage is lower than 3.4V the low battery alarm (BB sounds) voltage appears.
PAGE 3
(4.5V) c Operating Temperature：0°C-40°C/32°F-104°F 6.2 BU Transmitter a Transmitter Frequency：2.4G b Frequency：12 Channels（CH1：2413MHZ、CH2：2418MHZ、CH3：2423MHZ、CH4：2428MHZ CH5：2433MHZ、CH6：2438MHZ、CH7：2443MHZ、CH8：2448MHZ、CH9：2453MHZ、CH10： 2458MHZ CH11：2463MHZ、CH12：2468MHZ） c Power Supply：AC110～240V DC IN 5V 2W Current consumption 400MA d Operating Temperature：0°C-40°C/32°F-104°F FCC Statement 1. This device complies with Part 15 of the FCC Rules.
