Instructions / Assembly

Model ST2HWPLT-CA ST2CCWPLT-
CA
Suction/
Discharge
Diameter
2 in 2 in
Rotation
Velocity
3600rpm 3600rpm
Delivery 7,800 gph 12,680 gph
Suction Lift 10 ft 26 ft
Maximum
Pump Head
360 ft 104 ft
Water Pump
Type
Steel Housing
– Dual Cast
Iron Impellers &
Volute
Polyurethane
Housing,
Impeller,Volute
Manufacturer LIFAN LIFAN
Engine LF170F-P LF170F-P
Type 4HStrokeOHV
Single Cylinder
4HStrokeOHV
Single Cylinder
Maximum
Horsepower
(MHPa)
7HP 7HP
Displacement 212cc 212cc
Starting System Recoil Recoil
Fuel Tank
Capacity
2.5 Gallons 2.5 Gallons
Run Time 8 hrs 8 hrs
Fuel Type 87 Octane
Gasoline
87 Octane
Gasoline
Oil Type &
Amount
SAE
10w30w20oz
SAE
10w30w20oz
Low Oil Shutoff
Protection
Yes Yes
CARB Certified Yes Yes
Length 22 in 22 in
Width 18 in 18 in
Height 19 in 19 in
Dry Weight 72 lbs 45 lbs
Comments
MHPa = Maximum Horsepower
gph = gallons per hour
L/hr = Liters per hour
Product Specifications
5
