Z01 Packaging information
Doc ID 7474 Rev 10 9/12
Figure 16. SMBflat-3L footprint dimensions
Table 7. TO-92 dimensions
REF.
Dimensions
Millimeters Inches
Min. Typ. Max. Min. Typ. Max.
A1.35 0.053
B 4.70 0.185
C2.54 0.100
D4.40 0.173
E 12.70 0.500
F 3.70 0.146
a 0.50 0.019
Table 8. SMBflat-3L dimensions
Ref.
Dimensions
Millimeters Inches
Min. Typ. Max. Min. Typ. Max.
A 0.90 1.10 0.035 0.043
b 0.35 0.65 0.014 0.026
b4 1.95 2.20 0.07 0.087
c 0.15 0.40 0.006 0.016
D 3.30 3.95 0.130 0.156
E 5.10 5.60 0.201 0.220
E1 4.05 4.60 0.156 0.181
L 0.75 1.50 0.030 0.059
L1 0.40 0.016
L2 0.60 0.024
e 1.60 0.063
A
F
C
B
a
DE
D
A
L 2x
L
L2
L1
L1
L2 2x
E
E1
b4
c
e
b 2x
millimeters
(inches)
1.20
(0.047)
2.07
(0.082)
0.51
(0.020)
0.51
(0.020)
1.20
(0.047)
3.44
(0.136)
5.84
(0.230)
2.07
(0.082)
