Datasheet
Table Of Contents
- 1 Characteristics
- Table 1. Absolute maximum ratings
- Table 2. Electrical characteristics (Tj = 25 C, unless otherwise specified)
- Table 3. Static characteristics
- Table 4. Thermal resistances
- Figure 1. Maximum power dissipation versus on-state rms current (full cycle)
- Figure 2. On-state rms current versus lead (TO-92) or tab (SOT-223, SMBflat- 3L) temperature (full cycle)
- Figure 3. On-state rms current versus ambient temperature (free air convection full cycle)
- Figure 4. Relative variation of thermal impedance versus pulse duration (Zth(j-a))
- Figure 5. Relative variation of holding current and latching current versus junction temperature (typ. values)
- Figure 6. Relative variation of gate trigger current (IGT) and voltage (VGT) versus junction temperature
- Figure 7. Surge peak on-state current versus number of cycles
- Figure 8. Non-repetitive surge peak on-state current and corresponding value of I2t sinusoidal pulse width
- Figure 9. On-state characteristics (maximum values) (ITM = f(VTM)
- Figure 10. Relative variation of critical rate of decrease of main current versus (dV/dt)c
- Figure 11. Relative variation of critical rate of decrease of main current (dI/dt) versus junction temperature
- Figure 12. SOT-223 and SMBflat-3L thermal resistance junction to ambient versus copper surface under case
- Figure 13. Relative variation of static dV/dt immunity versus junction temperature (gate open)
- 2 Ordering information scheme
- 3 Packaging information
- 4 Ordering information
- 5 Revision history
Z01 Ordering information
Doc ID 7474 Rev 10 11/12
4 Ordering information
5 Revision history
Table 9. Ordering information
Order code
(1)
1. xx = sensitivity, y = voltage
Marking
(1)
Package Weight Base quantity Delivery mode
Z01xxyA 1AA2 Z01xxyA TO-92 0.2 g 2500 Bulk
Z01xxyA 2AL2 Z01xxyA TO-92 0.2 g 2000 Ammopack
Z01xxyA 5AL2 Z01xxyA TO-92 0.2 g 2000 Tape and reel
Z0103yN 5AA4 Z3y SOT-223 0.12 g 1000 Tape and reel
Z0107yN 5AA4 Z7y SOT-223 0.12 g 1000 Tape and reel
Z0109yN 5AA4 Z9y SOT-223 0.12 g 1000 Tape and reel
Z0103MUF Z3M SMBflat-3L 46.78 mg 5000 Tape and reel
Z0107MUF Z7M SMBflat-3L 46.78 mg 5000 Tape and reel
Z0109MUF Z9M SMBflat-3L 46.78 mg 5000 Tape and reel
Table 10. Document revision history
Date Revision Changes
Oct-2001 4 Last update.
10-Feb-2005 5 Package: TO-92 tape and reel delivery mode 5AL2 added.
09-May-2005 6
Table 4 on page 2: typo. mistake corrected
1. (dV/dt)c instead of (dI/dt)c
2. V/µs unit instead of A/ms
21-Apr-2006 7
Reformatted to current standard. Table 2 on page 2: Typo
corrected. Values for I
GT
split into two separate rows.
10-Oct-2006 8
Table 2: modified test conditions for (dV/dt)
c.
Changed “ambient”
to “lead or tab” in Figure 2.
20-Oct-2010 9 Package: SOT-223 13” tape and reel added = 6AA4
14-Dec-2010 10
Added package SMBflat-3L. Updated dimensions in Tabl e 6 .
Updated Figure 3 and Figure 12. Updated Table 5: Product
Selector.
