1 Absolute Maximum Ratings TIP42A
2/10
1 Absolute Maximum Ratings
Table 1. Absolute Maximum Ratings
Note: For PNP types voltage and current values are negative
Symbol Parameter Value Unit
V
CBO
Collector-Base Voltage (I
E
= 0)
60 V
V
CEO
Collector-Emitter Voltage (I
B
= 0)
60 V
V
EBO
Emitte-Base Voltage (I
C
= 0)
5V
I
C
Collector Current 6 A
I
CM
Collector Peak Current 10 A
I
B
Base Current 3 mA
P
TOT
Total dissipation at T
case
= 25°C
T
amb
= 25°C
65
2
W
W
T
stg
Storage Temperature -65 to 150 °C
T
J
Max. Operating Junction Temperature 150 °C
