Datasheet

1 Characteristics
Table 1. Absolute ratings (limiting values at 25 °C, unless otherwise specified)
Symbol Parameter Value Unit
V
RRM
Repetitive peak reverse voltage 60 V
I
F(RMS)
Forward rms current 10 A
I
F(AV)
Average forward current, δ = 0.5, square
wave
SMB Flat Notch, SMB Flat
T
L
= 115 °C
3 A
SMB, DO-201AD
T
L
= 105 °C
DO-15
T
L
= 72 °C
I
FSM
Surge non repetitive forward current
t
p
= 10 ms sinusoidal
100 A
P
ARM
Repetitive peak avalanche power
t
p
= 10 µs, T
j
= 125 °C
144 W
T
stg
Storage temperature range -65 to +150 °C
T
j
Maximum operating junction temperature
(1)
+150 °C
1. (dP
tot
/dT
j
) < (1/R
th(j-a)
) condition to avoid thermal runaway for a diode on its own heatsink.
Table 2. Thermal resistance parameter
Symbol
Parameter Max. value Unit
R
th(j-l)
Junction to leads
SMB Flat Notch, SMB Flat 15
°C/W
SMB 20
Junction to leads, lead length = 10 mm
DO-201AD 20
DO-15 35
For more information, please refer to the following application note :
• AN5088 : Rectifiers thermal management, handling and mounting recommendations
Table 3. Static electrical characteristics
Symbol
Parameter Test conditions Min. Typ. Max. Unit
I
R
(1)
Reverse leakage current
T
j
= 25 °C
V
R
= V
RRM
- 150 µA
T
j
= 100 °C
4 15
mA
T
j
= 125 °C
- 14 30
V
F
(1)
Forward voltage drop
T
j
= 25 °C
I
F
= 3 A
- 0.62
V
T
j
= 100 °C
0.53 0.61
T
j
= 125 °C
- 0.51 0.59
T
j
= 25 °C
I
F
= 6 A
- 0.79
T
j
= 100 °C
0.62 0.71
T
j
= 125 °C
- 0.6 0.69
1. Pulse test: t
p
= 380 µs, δ < 2%
STPS3L60
Characteristics
DS2134 - Rev 7
page 2/17
