Figure 21.
SMB recommended footprint
2.60
(0.102)
5.84
(0.230)
1.62
2.18
(0.086)
1.62
)
64
0
.
0
(
)
4
6
0
.
0
(
STPS3L60
SMB package information
DS2134
-
Rev 7
page 10/17
