Datasheet

4 Hardware specifications
General conditions (V
IN
= 3.3 V and 25 °C)
Table 1. Absolute maximum ratings
Ratings Min. Typ. Max. Unit
Storage temperature
range
- 40 + 95 °C
Supply voltage, V
IN
- 0.3 + 3.9 V
I/O pin Voltage (V
IO
five-volt tolerant pin)
- 0.3 + 3.9 V
RF saturation input
power
8 dBm
Table 2. Recommended operating conditions
Ratings Min. Typ. Max. Unit
Operating temperature
range
- 40 + 85 °C
Supply voltage, V
IN
1.7 3.3 3.6 V
Signals and I/O pin
voltage (according
supply voltage)
1.7 3.6 V
Table 3. Radio features
Ratings
Min. Typ. Max. Unit
Bluetooth version 4.2
Radiated transmit
power
+ 4.48 dBm
Receiver sensitivity - 84 dBm
RF frequency 2402 2480 MHz
HS_Startup_Time
(1)
512 µs
1. The HS_Startup_Time has been measured according to the “Bringing up the BlueNRG-1 device” (AN4818). The
HS_Startup_Time parameter is important because it permits minimization of the current consumption. A value that is too
short prevents the SPBTLE-1S from correctly sending/receiving packets. Users should set the typical value as indicated in
Table 3. Radio features .
4.1
Current consumption
Characteristics measured over recommended operating conditions unless otherwise specified. Typical value are
referred to T
A
= 25 °C, V
IN
= 3.0 V.
Current consumption values has been taken using the “BlueNRG current consumption estimation tool”, configured
to match the SPBTLE-1S configuration.
The tool is available on ST.com at:
http://www.st.com/en/embedded-software/stsw-bnrg001.html
Reported values have been taken configuring the tool as shown in the follow figure:
SPBTLE-1S
Hardware specifications
DS12065 - Rev 5
page 7/25
