Table 5. Pinout description
Module pin # Name
BlueNRG-1 Pin
(CSP package)
Function
Mode: "000" Mode: "001" Mode: "100" Mode: "010"
1 ADC2 D5 ADC input 2
2 ADC1 B4 ADC input 1
3 DIO4 C3 GPIO4 UART_RXD I2C2_CLK PWM0
4 DIO5 C2 GPIO5 UART_TXD I2C2_DAT PWM1
5 Vin A3, E6 Supply pin
6
ANATEST0/
DIO14/
A5 GPIO14 SPI_CLK ADC_DATA
7
DIO7/BOOT
(1)
D2 GPIO7 UART_CTS I2C2_DAT PDM_CLK
8 GND A4, B6, C1, F5 Ground
9 DIO6 D1 GPIO6 UART_RTS I2C2_CLK PDM_DATA
10 DIO8 D3 GPIO8 UART_TXD SPI_CLK PDM_DATA
11 DIO11 E2 GPIO11 UART_RXD SPI_CS1
12 DIO9 E1 GPIO9 SWCLK
SPI_IN
(2)
13 DIO10 F1 GPIO10 SWDIO
SPI_OUT
(3)
14 ANATES1 D4 Anatest1
15 DIO0 A2 GPIO0 UART_CTS SPI_CLK
16 DIO2 A1 GPIO2 PWM0 SPI_OUT PDM_CLK
17 DIO3 B1 GPIO3 PWM1 SPI_IN ADC_CLK
18 DIO1 B2 GPIO1 UART_RTS SPI_CS1 PDM_DATA
19 RESETN B3 Reset Pin
20 DIO12 F2
GPI12
(4)
21 N.C. N/A Must be left floating
22 N.C. N/A Must be left floating
23 N.C. N/A Must be left floating
1. The pin DIO7/BOOT is monitored by bootloader after power up or hardware Reset and it should be low to prevent unwanted
bootloader activation
2. The function SPI_IN indicates that the pin is always an input when configured for SPI. Thus in case of SPI master role, it
acts as MISO pin. In case of SPI slave role, this pin act as MOSI. See Table 5.
3. The function SPI_OUT indicates that the pin is always an output when configured for SPI. Thus in case of SPI master role, it
acts as MOSI pin. In case of SPI slave role, this pin act as MISO. See Table 5.
4. DI012 can only be General Purpose Input pins (not output).
Table 6. SPI pin function
SPI function
SPBTLE-1S SPI role = master SPBTLE-1S SPI role = Slave
SPI_IN SPI MISO SPI MOSI
SPI_OUT SPI MOSI SPI MISO
