Datasheet
Table 2. Electrical characteristics - parameter values (T
amb
= 25 °C, unless otherwise specified)
Type
I
RM
max at V
RM
V
BR
at I
BR
(1)
10 / 1000 µs 8 / 20µs
αT
V
CL
(2)(3)
I
PP
(4)
R
D
V
CL
(2)(3)
I
PP
(4)
R
D
25 °C 85 °C Min. Typ. Max. Max. Max. Max. Max. Max.
µA V V mA V A Ω V A Ω
10
-4
/°C
SM6T6V8AY/CAY 20 50 5.80 6.45 6.8 7.14 10 10.5 57 0.059 14.4 275 0.027 5.7
SM6T7V5AY/CAY 20 50 6.40 7.13 7.5 7.88 10 11.3 53 0.065 15.2 266 0.027 6.1
SM6T10AY/CAY 20 50 8.55 9.5 10.0 10.5 1 14.5 41 0.098 18.6 215 0.038 7.3
SM6T12AY/CAY 0.2 1 10.2 11.4 12 12.6 1 16.7 36 0.114 21.7 184 0.049 7.8
SM6T15AY/CAY 0.2 1 12.8 14.3 15 15.8 1 21.2 28 0.193 27.2 147 0.078 8.4
SM6T16V5AY/CAY 0.2 1 14.1 15.7 16.5 17.3 1 23.1 26 0.254 29 136 0.092 8.6
SM6T18AY/CAY 0.2 1 15.3 17.1 18 18.9 1 25.2 24 0.263 32.5 123 0.111 8.8
SM6T22AY/CAY 0.2 1 18.8 20.9 22 23.1 1 30.6 20 0.375 39.3 102 0.159 9.2
SM6T24AY/CAY 0.2 1 20.5 22.8 24 25.2 1 33.2 18 0.444 42.8 93 0.189 9.4
SM6T27AY/CAY 0.2 1 23.1 25.7 27 28.4 1 37.5 16 0.569 48.3 83 0.240 9.6
SM6T30AY/CAY 0.2 1 25.6 28.5 30 31.5 1 41.5 14.5 0.690 53.5 75 0.293 9.7
SM6T33AY/CAY 0.2 1 28.2 31.4 33 34.7 1 45.7 13.1 0.840 59.0 68 0.357 9.8
SM6T36AY/CAY 0.2 1 30.8 34.2 36 37.8 1 49.9 12 1.01 64.3 62 0.427 9.9
SM6T39AY/CAY 0.2 1 33.3 37.1 39 41.0 1 53.9 11.1 1.16 69.7 57 0.504 10.0
SM6T42AY/CAY 0.2 1 36 40 42.1 44.2 1 58.1 10.3 1.35 76 52 0.611 10.0
SM6T47AY/CAY 0.2 1 40 44 46.7 49.0 1 64.5 9.7 1.59 84.0 48.0 0.728 10.1
SM6T56AY/CAY 0.2 1 47.6 53.2 56 58.8 1 76.6 7.8 2.28 100 40 1.030 10.0
SM6T68AY/CAY 0.2 1 58.1 64.6 68 71.4 1 92 6.5 3.17 121 33 1.503 10.4
SM6T75AY/CAY 0.2 1 64.1 71.3 75 78.8 1 103 5.8 4.17 134 30 1.84 10.5
SM6T82AY/CAY 0.2 1 70.0 77.8 81.9 86.0 1 113 5.5 4.91 146 27.0 2.22 10.5
1. To calculate V
BR
versus T
j
: V
BR
at T
j
= V
BR
at 25 °C x (1 + αT x (T
j
- 25))
2. To calculate V
CL
versus T
j
: V
CL
at T
j
= V
CL
at 25 °C x (1 + αT x (T
j
- 25))
3. To calculate V
CL
max versus I
PPappli
: V
CLmax
= V
BR
max + RD x I
PPappli
4. Surge capability given for both directions for unidirectional and bidirectional devices
SM6TY
Characteristics
DS6905 - Rev 10
page 3/15
