Wherever boundaries are being pushed, Spicer parts are there. That is why Spicer parts can deliver innovations that meet the
latest performance demands. That commitment to the specialty market is what has made the Spicer brand the most trusted
name in the business.
Spicer performance spools offer tremendous advantages for racing enthusiasts and hardcore off-roaders, providing features
and benefits that standard differentials cannot offer. Spicer performance spools replace the need for a differential case, thus
eliminating failures from high-torque, high-impact situations.
Spicer Parts. Built Tough for the Performance Market.
PERFORMANCE
SPOOLS
Spicer spools are not recommended for everyday street driving, but they offer
incredible benefits in performance applications. Ask your Spicer parts representative
about whether spools are right for your vehicle, and visit www.danaunleashed.com to see
our full line of specialty parts for off-road and racing vehicles!
Dana Aftermarket Group
PO Box 321 Toledo, Ohio 43697-0321
Phone: [phone]
www.danaunleashed.com
Form # PERF-SPOOLS-102013
Copyright Dana Limited, 2013.
All rights reserved. Dana Limited.
Printed in U.S.A.
»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»»
Forged from chromoly 4130 steel
• Provides optimal strength
Heat treated and metallurgically
tested
• Ensures ideal hardness for performance
applications
Available in lightweight versions
• Delivers lighter rotating mass
Available for all makes
21 SKUs available
Dana # Model Spline Notes
2022497 Chrysler 8.75" 30
2023540 Dana 44
™
30
MINI SPOOL - Replaces
Inner Gear Kit
2023397 Dana 44
™
30 3.92 and Up
2023547 Dana 44
™
30 3.73 and Down
2023542 Dana 60
™
30 4.56 and Up
2023545 Dana 60
™
30 4.10 and Down
2023541 Dana 60
™
35 4.10 and Down
2023546 Dana 60
™
35 Thin Flange
10002216 Dana 60
™
35 4.56 and Up
10002217 Dana 60
™
40 4.56 and Up
10002214 Ford 8.8" 31
Requires Use Of C-Clip
Eliminator Kit
10002219 Ford 9" 28 Lightweight Design
2022501 Ford 9" 31
2023544 Ford 9" 35 2.8" & 3.0" Cases
2022499 Ford 9" 35 Lightweight Design
10002220 Ford 9" 35
45 Degree Mark Williams
Axles
10002218 Ford 9" 40 Lightweight Design
2022498
GM 10.5" 14
Bolt
30 4.10 and Down
2022500 Model 20 29 3.08 and Up
2023543
Toyota 8" 4
cylinder
30
2023539 Toyota V6 30
Talk to your Dana Aftermarket Performance representative today—or visit www.danaunleashed.com.
