connected to your Remote Switch Box and tie them together with the Black (Negative)
cable of your Remote Switch Box. Finally. connect all of these Negative Cables to the
negative post of your battery.
Programming Remote Control: (For Warranty Only)
Disconnect:
To disconnect Controller , open unit by removing the Qty. 8 screws (4 on each side). Once
opened, locate the Receiver Board . The Receiver Board will be on the end of the main PCB
standing straight up and will have a blue LED and a white rectangular button on it. Hold the
white button down until the blue LED stays lit and this will disconnect Controller .
Connect:
To reconnect Controller, open unit by removing the Qty. 8 screws (4 on each side). Once opened
locate the Receiver Board . The Receiver Board will be on the end of the main PCB standing
straight up and will have a blue LED and a white rectangular button on it. Press the white button
down, this will cause the blue LED to blink. Once the LED starts to blink, press any button on the
Controller and this will connect the Controller to the receiver unit.
Unpacking your STL Product
Unpack your unit to identify all parts including but not limited to: light bar, switch box, brackets,
screws, bolts, wiring harness, fuses, etc.
Some parts may be in small bags.
Some products may be packaged inside boxes of other products.
Some parts such as Gutter Brackets, may be in the foam protection. Double check that no parts
are left within the foam protection or left in the box.
Instructions for Mounting, Wiring and Programming
IMPORTANT! To ensure proper installation installers are required to have a good understanding
of automotive electronic, systems and procedures for proper installation. When you are drilling
