Installation Manual

2809 Business Park Dr • Buda • Texas •78610
Phone [phone] • Fax [phone] • Email [e-mail]
4 (c) 2016 SpeedTech Lights, Inc.
- FAILURE TO FOLLOW THESE SAFETY PRECAUTIONS, WARNINGS, NOTICES, AND INSTRUCTIONS COULD
RESULT IN DAMAGE TO THE PRODUCT OR VEHICLE THAT WILL VOID YOUR WARRANTY AND/OR CAUSE
SERIOUS INJURY TO YOU AND YOUR PASSENGER.
SUMMARY OF THE WIRELESS REMOTE SWITCH CONTROL BOX:
With an original design, the STL Wireless Remote Switch Box contains the light control options needed for
all emergency vehicles.
Powered by 12V
Remotely power up to 6 units
Range of up to 100 feet
Labels on switch: A/B/C/D/E/F
Up to 10 amps per switch
Allows for master power control
Compatible with all STL and third party units
Set includes 1 remote controller
Remote uses A23 battery
Includes 7 inches of 18 gauge cable
Power Supply Dimensions: 3" L x 2" H x 1" D
How the STL Wireless Remote Switch Control Box Operates
Power On/Off Switches:
A. Red
B. Red
C. Red
D. Red
E. Red
F. Red
Red Cable – Positive (+12VDC)
Black Cable – Negative (Ground)
Wiring Instructions:
Connect the Positive (+12VDC) cable of your light unit and connect it to one of the A, B, C, D,
E, F colored cable of your Remote Switch Box of your choosing. Do this for every light unit that
you want to connect to your Remote Switch Box. Now take all the remaining Negative cables
from all your light units
