Spec Sheet

Stack Dryer
AO21-0027
speedqueencommercial.com
Speed Queen by Alliance Laundry Systems
©2021 Alliance Laundry Systems LLC
ADA Compliant - Lower Unit
Note: Not all options are available for all models. Refer to the price list for the available models and options.
* Information shown applies to highest end control available.
For the most accurate information, the installation guide should be used for all design and construction purposes. Due to continuous product improvements, design and specifications
subject to change without notice. The quality management systems at Alliance Laundry Systems are registered to ISO 9001.
Specifications
Model/ Control Option Electronic
Homestyle (EH)
LSEE5AGS173T W01,
LSEE5AGW173T W01,
LSGE5AGS113TW01,
LSGE5AGW113TW01
E-Mech (EM)
SSEMNAGS173T W01,
SSGMNAGS113TW01
Control Location
Front
Capacity - lb (kg)
18 (8.2)
Cylinder Volume - cu. ft. (liters)
7.0 (198)
Overall Width - in (mm)
26.875 (683)
Overall Depth - in (mm)
28 (711)
Overall Height - in (mm)
78.17 (1986)
Motor Power Consumption - hp (kw)
0.33 (0.25)
Available Heat Sources
Gas or Electric
Available Heating Element (Electric W)
5350 @ 240V
Gas Inlet Connection - in (mm)
3/8 (9.5)
Gas Consumption - BTU/Hr
22,500
Exhaust Outlet DIA. - in (mm)
4 (102)
Exhaust Airow - cfm (liters/sec)
220 (105)
*Available Cycles
Regular, Perm Press,
Delicate, Time Dry,
Quick Dry, Fluff Up
Water Pressure -PSI (Bar)
20-120 (1.4/8.3)
Cycle Indicator Lights
Yes
Cylinder Finish
Galvanized
Available Colors
White
Door Type (Solid/Window)
Solid or Window
Available Electrical
Requirements -
Voltage/Hz/Ph -
Circuit Amperage
Electric
120/240/60/1 -30
120/208/60/1
Gas
120/60/1 - 15
Shipping Dimensions
Approx. - in (mm)
Width
30 (762)
Depth
33 (838)
Height
80 (2032)
Net Weight - lb (kg) Electric
262 (119)
Gas
270 (122)
Shipping Weight - lb (kg) Electric
272 (123)
Gas
280 (127)
Agency Approvals Electric
cULus
Gas
cCSAus
A
B
C
E
D
A. Overall Width - in (mm)
26.875 (683)
B. Overall Depth - in (mm)
28 (711)
C. Overall Height - in (mm)
78.17 (1986)
D. Floor To Door Opening - in (mm)
15.44 (392)
E. Door Swing - in (mm)
23.5 (597)
