Owner manual

Splitting Force (tons)
Cylinder Size 1000 PSI 1500 PSI 2000 PSI 2500 PSI 3000 PSI 3500 PSI
3" 3.5 5.3 7.1 8.8 10.6 12.4
3-1/2" 4.8 7.2 9.6 12.0 14.4 16.8
4" 6.3 9.4 12.6 15.7 18.8 22.0
4-1/4" 7.1 10.6 14.2 17.7 21.3 24.8
4-1/2" 7.9 11.9 15.9 19.9 23.9 27.8
5" 9.8 14.7 19.6 24.5 29.5 34.3
Cylinder Size 5 GPM 10 GPM 15 GPM 20 GPM 25 GPM
3" x 24" 15.4 7.7 5.1 3.9 3.1
3-1/2" x 24" 21.8 10.9 7.3 5.4 4.4
4" x 24" 28.3 14.2 9.4 7.1 5.7
4-1/4" x 24" 32.4 16.2 10.8 8.1 6.5
4-1/2" x 24" 36.6 18.3 12.2 9.2 7.3
5" x 24" 45.0 22.5 15.0 11.3 9.0
Cycle Time (seconds)
CAUTION: This log splitter is designed for tractors with pressure ratings under 3200 psi.
Warranty will be voided if used on tractors that exceed pressure settings of 3200 psi.
Do not exceed the pressure rating of the cylinder and valve manufacturers
TractorCategories 1 and 2
MaximumSplittingForce Depends on tractor*
CycleTime Depends on tractor*
Maximum Log Length 26”
Cylinder 4” diameter x 24” stroke
Valve Auto-return
Beam Size 6” x 9”
Wedge 7” high with spreader wings
Hitch Tractor 3-point
Height 42” horizontal
72” vertical
Width 22”
Length 72”
Shipping Weight 365 lbs.
*SplittingforceisdeterminedbycylindersizeandtractorPSI.Cycletimedependson
cylinder size and GPM’s that the tractor produces. Tractor should ideally produce 8-15
GPM at 1500 to 2500 PSI Do not exceed 3200 PSI. See tables below for approximate
splitting force and cycle time.
SPECIFICATIONS
Part No.S53010600
