3-POINT HITCH VERTICAL/HORIZONTAL LOG SPLITTER MODEL NO. S400197N0 Owner’s Manual ASSEMBLY & OPERATING INSTRUCTIONS WARNING: All operators must read this manual before operating this log splitter. Follow the safety instructions in the manual and in decals attached to the product. Failure to do so could result in serious injury or death. LS47-631-0712 Rev.
Table of Contents Important Safety Information................................................................................................................. Page(s) 1-5 Intended Use ......................................................................................................................... 1 Personal Protective Equipment ............................................................................................... 1 General Safety ............................
WARNING: Read and thoroughly understand all instructions and safety information before assembling or operating this log splitter. Failure to do so may cause serious injury or death. Do not allow anyone to operate this log splitter who has not read this manual. As with all power equipment, a log splitter can be dangerous if assembled or used improperly. Do not operate this log splitter if you have doubts or questions concerning safe operation.
SAFETY DECALS Make sure that all safety warning decals are in good condition and readable. Always replace missing or defaced decals. Write us or call 1-800-525-8322 and they will be sent to you at no charge.
PREPARATION OF THE LOG Both ends of the log should be cut as square as possible to help prevent the log from riding out of the splitter during operation. Do not split logs greater than 26 in. in length. EVER WORK AREA NEVER operate the log splitter on slippery, wet, muddy or icy ground. ONLY operate your log splitter on level ground. Operating on a slope could cause the log splitter to roll over or logs to fall off. NEVER operate your log splitter in an enclosed area.
REPAIR AND MAINTENANCE SAFETY NEVER operate your log splitter when it is in poor mechanical condition or in need of repair. Periodically check that all nuts, bolts, screws, hydraulic fittings and hose clamps are tightened. NEVER alter your log splitter in any manner such as adding a rope or extension to the control lever or adding to the width or height of the wedge. Such alterations may cause your log splitter to be unsafe and will void the warranty.
ASSEMBLY INSTRUCTIONS NOTE: This log splitter was partially assembled at the factory. Refer to the drawing and parts list should it become necessary to disassemble the unit for repair or replacement of parts. STEP 1: Remove all the components from the crate. Inspect each piece for shipping damage. If any part is damaged, contact your dealer or delivering carrier. STEP 2: Attach the four legs to the A-frame stand (18) using the 5/16 in. NC x 1-1/2 in. hex cap screws (28), 5/16 in.
OPERATING INSTRUCTIONS WARNING: Read and thoroughly understand all instructions and safety information before operating this log splitter. Failure to do so may cause serious injury or death. Do not allow anyone to operate this log splitter who has not read this manual. As with all power equipment, a log splitter can be dangerous if assembled or used improperly. Do not operate this log splitter if you have doubts or questions concerning safe operation.
PARTS BREAKDOWN FOR S400197N0 REFERENCE NUMBER PART DESCRIPTION NUMBER 3-Point Hitch Vertical/Horizontal Log Splitter Complete NUMBER REQUIRED 1 S400197N0 3-Point Hitch Vertical/Horizontal Log Splitter Complete 1 1 S401411R0 Beam (6” x 9”) for 400197N0 1 2 S40141700 Wedge 1 3 O/L 1/2 in. NC x 3 in. Hex Cap Screw (Grade 5) 1 4 O/L 1/2 in. Lockwasher 1 5 O/L 1/2 in. NC Hex Nut 1 6 S390118B0 4 in. x 24 in.
3-POINT HITCH LOG SPLITTER Valve Assembly Page 8
SPECIFICATIONS Tractor Categories 1 and 2 Maximum Splitting Force Depends on tractor* Cycle Time Depends on tractor* Maximum Log Length 26” Cylinder 4” diameter x 24” stroke Valve Auto-return Beam Size 6” x 9” Wedge 7” high with spreader wings Hitch Tractor 3-point Height 42” horizontal 72” vertical Width 22” Length 72” Shipping Weight 365 lbs. *Splitting force is determined by cylinder size and tractor PSI.
