User guide

Spectrex Inc. - SharpEye
TM
ML & MU Flame Detector Manual – TM 767100, Rev. A, April 2005
43
Specifications
Mechanical
Explosion Proof Enclosure:
NFPA (designed to meet)
Class I, Division 1 & 2 Groups B, C and D
Class II, Division 1 & 2 Groups E, F, and G
ATEX EX II2G NEMKO 02ATEX255
EExd IIB T5 50˚C per En 50-014 & EN50-018
Electrical
Power: 8 VDC Max
6 x Rechargeable1.2 VDC NiCd Batteries
Current: 2.5A Avg.
Charge: 400mA for 14 Hours
Environmental
Temperature Range: -4º F (-20º C) to 122º F (50º C)
Vibration Protection: 1g (10-50hz)
Water and Dust: IP 67 per EN 60529
Physical
Dimension: 11.5 x 10.1 x 3.9 in (292 x 258 x 100 mm)
Weight: 7.5 lb. (3.4 Kg)
Range*
Model Standard Extended Range
with optional Beam
collimator
20/20ML 14.5 ft (4.5m) 29 ft (9m)
20/20MU 14.5 ft (4.5m) 29 ft (9m)
* The minimum distance from the detector is 20 inches (50cm)
* At extreme temperatures 15% Max. Reduction
