If the button is blank and the current job contains at least one
polyline, you will be prompted to select an existing polyline. Once
selected, future points stored with this linework command will be
appended to the selected polyline.
Props: A single polyline can contain different
line types. The Props command will open the
Auto Linework Properties
dialog box, shown
here, where when the checkbox is checked, the
linework command will always switch back to
the specified default linework command after
changing and storing a different line type for a particular feature.
Add… : allows you to create a new linework command.
Remove… : removes the selected linework command.
Remove All… : removes all the existing linework commands.
Note: All linework shots require at least two points with a particular
linework command before a polyline segment is created. If only the
initial point has been stored, no polyline segment is yet created.
