Job Menu

R-37

Note: When running in leveling mode, the Instrument Settings… can

be selected for Manual Mode to open the Level Method screen

described on Page R-41.

Instrument Settings : opens the next Instrument Settings screen

where the settings in the selected instrument profile can be modified.

Note: When editing an existing instrument profile, you cannot modify

the instrument brand or model.

Create New Instrument : opens the next Instrument Settings screen

where you can configure the settings for a new instrument and create

a new instrument profile.

Activate : activates the selected instrument profile.

GeoLock : opens the GeoLock Settings screen (Page R-166).

Delete : deletes the selected instrument profile.

Import : imports an instrument profile from an instrument profile

file that was previously loaded on the data collector.

Export : saves the selected instrument profile to a file, which can

then be transferred to another data collector and then imported.

Warning: Performing a hard reset on the data collector will result in

all the user-created instrument profiles to be deleted. It is

recommended that all instrument profiles be exported to files so in

the event of a hard reset they can be recovered using the Import

routine.
