Solve : will perform the rotation on the selected points and change
the coordinates accordingly. Information will be written to the raw
data file detailing the adjustment.
Traverse Adjust
Adjust Traverse Adjust.
The Traverse Adjust wizard is a series of screens that allow you to
adjust a closed traverse for angular error and/or perform a compass
rule adjustment on a closed or open traverse.
Choose Your Traverse: is used to select a
traverse to adjust from the following options:
• Tap Polyline… : is used to tap an existing
polyline from a map view.
• To/From… : Opens the Point List screen
(Page R-449) where a point list can be
created.
; Angle Adjust: When checked, will perform
an angle adjustment to the closed traverse. An
angle adjustment will apply the angular error
equally among all of the angles of the closed
traverse and adjust the coordinates for all but the first two traverse
points. (The first leg of the traverse is not adjusted.)
; Compass Rule: When checked, will perform a compass rule
adjustment on the selected traverse.
; Adjust elevation: when selected, the elevations for the traverse
points are also adjusted from the compass rule adjustment.
; Adjust Sideshots: When checked, any side shots that were stored
while occupying the traverse points in the selected traverse will also
be adjusted.
The side shot locations will be recomputed using the original angles
and distances stored in the raw data file along with the adjusted
locations of the occupy and backsight points.
