Solve : will compute the curve based on the selected points.
Traverse : opens the Traverse on Curve screen (Page R-394), where
the curve can be included in a traverse.
Layout : opens the Curve Layout screen (Page R-387), where the
location of points on a curve can be computed at any station interval.
Results
Radius: is the distance from the radius point to the curve.
Length: is the arc length.
Chord: is the chord length.
Delta: is the deflection angle.
Tangent: is the distance from the PC or PT to the PI.
Mid Ord.: is the distance between the curve and the chord at the
center of the curve’s length.
External: is the minimum distance between the PI and the curve.
Deg. Arc: is the deflection angle that results in a 100-ft. arc length.
Deg. Chord: is the deflection angle that results in a 100-ft. chord
length.
Segment: is the area between the arc length and the chord.
Sector: is the area between the arc length and the two edge radii.
Fillet: is the area between the arc length and the tangents.
