Reference Manual

Survey Pro Reference Manual
R-362
Point in Direction
Cogo Point in Direction.
The Point in Direction screen will calculate and store the position of a
new point after providing a distance and direction from a known
point.
From point: is the point name of the reference
point used for locating the new point.
Azimuth / Bearing : is the direction from the
reference point to the new point.
+/- Angle: is the angle added to the Azimuth /
Bearing to modify the direction to the new
point.
Note: To subtract an angle from the specified
azimuth or bearing, enter a negative +/- Angle
value.
Horiz. Dist: is the horizontal distance from the reference point to the
new point.
Vert. Dist: is the vertical distance from the reference point to the new
point.
Store point: When this is checked, the computed point will be stored
with the name specified here.
Solve : will compute the location for, and optionally store the new
point.
