Reference Manual

Stakeout Menu
R-307
Stake Line and Offset
Stakeout Line and Offset.
The Stake Line and Offset screen is used to stake stations on a line,
or at an offset to it, at fixed intervals.
: opens the Stakeout Settings screen (Page R-50).
Start Point: defines the first point of the line to
be staked.
End Point / Direction : defines the second
point of the line, or the direction of the line to
be staked, respectively.
Begin Station: defines the station associated
with the Start Point.
Backsight… : opens the Backsight Setup screen
(Page R-122).
Next> : opens Screen Two.
Stake Line and Offset – Screen Two
Station to Stake: is the desired station that you want to stake.
Station Interval: is the value that is added to
the Station to Stake after the
Next Station button is pressed.
Next Station : advances the Station to Stake by
the Station Interval.
Offset: defines the offset distance and if the
offset occurs to the right of the line, when
R is
selected, or left, when
L is selected. The right
or left side is referenced while viewing the line
from the Start Point.
