Shoot From Two Ends
Survey Shoot From 2 Ends.
The Shoot From 2 Ends screen is used to provide more accurate
vertical closure to a traverse. The routine requires that a foresight
point is shot, but it is not stored until after it is occupied and another
shot is taken to the previous occupy point. The coordinates for the
foresight point are computed from an average of data gathered at
each occupy point.
: is a shortcut to the Surveying and
Repetition Settings
screens (Page R-44 and R-
56 respectively).
Foresight:
is the name given to the next stored
point.
Description: is the description given to the
next stored point.
HR: is the length of the rod.
: opens the Smart Target options (Page R-
456).
Num
ber of Sets: is the desired number of sets required when
shooting each foresight. You must select at least one set.
Traverse : will prompt you to shoot the
Foresight point. After each set is performed,
the Move To Other End
dialog box will open
(shown here) and prompt you to set up on the
new point and enter a new instrument and rod
height. The New Occupy Point
dialog box
(Page R-131) will open and inform you of the
updat
ed points.
BS Setup… : opens the Backsight Setup screen
(Page R-122) where the current backsight can
be modified.
