Radio Settings
Job Settings Radio Settings.
The Radio Settings
card is used to configure the base radio when
using a local base/radio configuration, or configure a cellular phone as
a data modem for Internet base corrections. The choice made from the
upper radio buttons determines the remaining options on the screen.
Base/Rover Radio RTK: should be selected when using a local base
receiver/radio configuration.
• Use CMR Station Index: should be checked in situations
where more than one base is in range of the rover, allowing it
to distinguish one from the other. Enter a unique value from
0-31 in the corresponding field.
• Change Radio Settings: opens the Change Radio Settings
screen, described below.
Internet (Single Base/NTRIP) RTK: should be selected when using a
cellular phone as a data modem for connecting to the Internet to
receive Single Base/NTIP corrections.
• Dial-Up Connection: is where you select any existing dial-up
connections that have been added from the Manage
Connections routine.
• Manage Connections : is a shortcut to the Windows’ Start >
Settings > Connections > Connections screen where you can
add/manage modem (cell phone) connections. Tapping the
button from that screen will open the help for it. For more
