Installation & Assembly
4
CURRENT DETECTION
TEST BUTTON
RESET BUTTON
INDICATOR LIGHT
NOTE: Press the TEST button (then RESET button) every month to ensure proper operation.
• Insert the Power Adapter into the electrical outlet.
• Press the Reset Switch. The Indicator Light on the power adapter will illuminate to show that the power is ON.
POWER CONNECTION SET-UP
5
When the unit powers on for the first time, it will perform an Automatic Testing Routine. This routine is as
follows:
• The Main Unit will beep once, then the purple light on the Function Knob will flash on and off, and the testing
routine will begin. The light will continue to flash throughout the test. Do not use the seat during this time.
• At the conclusion of the test, the flashing purple light on the function knob will turn solid, signaling that the test
is complete.
• The Bidet Seat is now ready for use.
INITIAL START UP TEST
ROUTINE CLEANING
1. Unplug from electrical outlet while cleaning.
2. Use only a soft, damp cloth to clean. Avoid using harsh chemicals.
3. Once cleaning is completed and all surfaces are dry, plug the Power Adapter back into the electrical outlet.
NOTE: Do not rinse the surface of the product directly with water during maintenance.
NEUTRAL CLEANER
NOZZLE MAINTENANCE
NOTE: Do not pull the Nozzle Housing to prevent damage of the Nozzle and motor.
1. To clean the nozzle, perform a Short Press to the Rear Cleaning Button while not sitting on the unit. The nozzle
will extend outward to allow access for cleaning.
2. The Spray Nozzle can be removed and cleaned separately. While holding the Nozzle Housing with one
hand, remove the Nozzle itself by gently pulling it towards you with the other hand.
3. Once cleaning is completed, reinstall the Nozzle to the Nozzle Housing. Press the "Stop" button on the main
unit to return the Nozzle Rod to its normal position.
SELF-CLEANING WATERWAY MAINTENANCE
NOTE: Ensure the power supply is unplugged when working on unit.
When the Self-Cleaning Waterway is blocked, or if there is no water coming out during Self-Cleaning process:
1. Turn OFF the water supply at the Stop Valve.
2. Unplug the Power Supply Cord from the electrical outlet.
3. Remove the Seat by following STEP 2, press the Flow Reset Valve in the middle with a flat tip screwdriver,
then reinstall the Seat, and turn ON the water supply at the Stop Valve.
4. If there is still no water coming out after pressing the Flow Reset Valve, use a flat tip screwdriver to unscrew
the Reset Valve Cover, then remove the Flow Reset Valve. Clean it with a small brush. Once cleaned, re-seat the
components into the shaft shown below.
5. Reinstall the Seat by following STEP 2, then turn ON the water supply.
FLOW RESET
VALVE
RESET VALVE
COVER
FILTER MAINTENANCE
FILTER
(REMOVE WITH A NEEDLE NOSE PLIER)
FILTER WASHER
TOILET SUPPLY LINE
BIDET SUPPLY LINE
SUPPLY TEE
If poor spray performance occurs under normal conditions:
1. Turn OFF the water supply at the Stop Valve.
2. Using an Adjustable Wrench, unscrew both the Supply Line to the Toilet and to the Bidet Seat from the
Supply Tee.
3.
Remove Filter and Filter Washer using Needle Nose Pliers. Clean out Filters under running water using a small brush.
4. Reinstall Filters and Water Supply Lines to Supply Tee.
Note: Ensure that the Filter is reinstalled in the orientation shown.
5. Wrench tighten connections. Take care to not over-tighten or damage may occur.
• Turn OFF water supplies at the Stop Valve.
• Unthread existing Toilet Supply Line from Toilet Fill
Valve. The Toilet Fill Valve inlet is located at the base
of the Toilet Tank.
• Install the included Tee on to the Toilet Fill Valve.
Do NOT over-tighten or damage may occur.
• Re-install Toilet Supply Line to bottom port of Tee.
TOILET FILL VALVE
EXISTING TOILET
SUPPLY LINE
INCLUDED
SUPPLY TEE
TOILET FILL VALVE
EXISTING TOILET
SUPPLY LINE
INCLUDED
SUPPLY TEE
BIDET WATER
INLET LINE
• Install the Bidet Water Inlet Line to the Side Port of the
Supply Tee.
TOILET FILL VALVE
EXISTING TOILET
SUPPLY LINE
TURN “OFF”
STOP VALVE
TURN “ON”
STOP VALVE
CHECK FOR
LEAKS
• Tighten connections. Take care to not over-tighten
connections or damage may occur.
• Turn “ON” water supply at the Stop Valve and inspect
for leaks.
PLUMBING CONNECTIONS
