Installation Guide

ACTIVATION AND TESTING
The eye wash is activated by pulling spray heads downward 90° over the sink basin. Once the unit is activated, water will discharge from the spray outlets until the eye wash spray heads are manually pushed back
to the vertical off position.
TESTING PROGRAM
The American National Standards Institute (ANSI) states that all safety emergency equipment shall be activated on a weekly basis to flush the line and verify proper operation. Speakman Company furnishes a testing
record tag (91-0635) with each unit. On this tag the date of inspection and the inspector’s initials should be noted.
SE-577-SD / SE-577-SD-ADA REPAIR PARTS
SPEAKMAN
®
RPG05-104024 SPRAY HEAD ASSEMBLY
RPG05-104029 FLOW CONTROL AND SCREEN
RPG05-104025 SPRAY HEAD DUST CAP (QTY 2)
RPG21-0196 AERATOR (QTY 2)
RPG45-104026 SEALS AND SLIP RINGS
RPG05-106027 VALVE SPINDLE
RPG01-104028 MOUNTING HARDWARE
ITEM NO. PART NO. DESCRIPTION
