Users Manual

permissible gain indicated. Antenna types not included in this list that have a gain
greater than the maximum gain indicated for any type listed are strictly prohibited
for use with this device.
Unique antenna connector (IPEX) must be used on the Part 15 authorized
transmitters used in the host product.
Antenna
Type
Antenna Model
Maximum Gain (dBi) Remark
2.4 GHz 5GHz
PCB
FML2.4W45A-
160-MHF4L
3.13 dBi 4.94 dBi
If the FCC identification number is not visible when the module is installed inside
another device, then the outside of the device into which the module is installed
must also display a label referring to the enclosed module. This exterior label can
use wording such as the following: “Contains Transmitter Module FCC ID: RYK-
WNFT237ACNBT” Or “Contains FCC ID: RYK-WNFT237ACNBT”
The modular transmitter is only FCC authorized for the specific rule parts (i.e., FCC
transmitter rules) listed on the grant, and the host product manufacturer is
responsible for compliance to any other FCC rules that apply to the host not covered
by the modular transmitter grant of certification. The final host product still requires
Part 15 Subpart B compliance testing with the modular transmitter installed.
The final host manual shall include the following regulatory statement: FCC part
15.19 and 15.105.
