TAPE AND REEL DIMENSIONS in millimeters
Fig. 11 - 7" Reel, 3000 Pieces
Drawing-No.: 9.800-5096.01-4
Issue: 5; 20.12.2016
Form of the leave open of the wheel is supplier specic.
Ø 177.8 max.
Ø 55 min.
14.4 max.
Ø13
+0.5
-0.2
1.5 min.
Ø20.2 min.
8.4
+2.5
8.4
+0.15
Z
Z 2:1
Technical drawings
according to DIN
specication.
