PACKAGE DIMENSIONS in millimeters
Not indicated tolerances ± 0.1
2
(0.6)
0.87
Technical drawings
according to DIN
specication
0.45 (6 x) 0.4 (6 x)
Pin 1 marking
Top View Pinning
1 GND
2 SDA
3 INT
A
DD
4
SCL 5
V
DD
6
Recommended Footprint
2.3
1.6
0.55 (6 x)
0.3 (6 x)
0.35 (4 x)
Drawing No.: 6.550-5348.01-4
Issue: 1; 19.02.16
2
2
1
1
0.65 (4 x)
