Data Sheet

PAM2401
Document number: DS37285 Rev. 1 - 2
7 of 10
www.diodes.com
May 2014
© Diodes Incorporated
PAM2401
NEW PRODUCT
A
Product Line o
f
Diodes Incorporated
Typical Performance Characteristics (cont.) (T
A
= +25°C, V
IN
= 3.3V, V
OUT
= 5V, unless otherwise noted.)
0 100 200 300 400 500 600 700 800 900 1000 1100
0.8
1.0
1.2
1.4
1.6
1.8
2.0
2.2
2.4
2.6
Minimum startup input voltage(V)
Output Current(mA)
Vo=3.3V
Vo=3.6V
Vo=4.2V
Vo=5V
Figure 10 Minimum Startup Input Voltage vs. Output Current
Figure 11 Enable Turn On (I
O
= 1A)
(CH1: Enable; CH2: V
OUT
; CH3:SW; CH4: I
O
)
Figure 12 Enable Turn Off (I
O
= 1A)
(CH1: Enable; CH2:V
OUT
; CH3:SW; CH4:Io)
Figure 13 Output Ripple (I
O
= 0A)
(CH1:SW; CH2: V
OUT-AC
; CH4:IL)
Figure 14 Output Ripple (I
O
= 0.2A)
(CH1: SW; CH2:V
OUT
-
AC
; CH4:IL)
Figure 15 V
OUT
Short Protection (I
O
= 1A)
(CH2:V
OUT
; CH3:IL)
Figure 16 V
OUT
Short Recovery (I
O
= 1A)
(CH2: V
OUT
; CH3: IL )
