Data Sheet

SPEC NO: DSAI2506 REV NO: V.1 DATE: APR/01/2008 PAGE: 2 OF 6
APPROVED: WYNEC CHECKED: Allen Liu DRAWN: Y.F.Lu ERP: 1203001960
Selection Guide
Notes:
1. θ1/2 is the angle from optical centerline where the luminous intensity is 1/2 the optical centerline value.
2. Luminous intensity/ luminous Flux: +/-15%.
Absolute Maximum Ratings at TA=25°C
Electrical / Optical Characteristics at TA=25°C
Note:
1. 1/10 Duty Cycle, 0.1ms Pulse Width.
Part No. Dice Lens Type
V
iewing
Angle [1]
Min. Typ. 2θ1/2
APT3216QWF/D White (AlInGaN) YELLOW FLUORESCENT 110 250
120
°
Iv (mcd) [2]
@ 20mA
Parameter White Units
Power dissipation 120 mW
DC Forward Current 30 mA
Peak Forward Current [1] 150 mA
Reverse Voltage 5 V
Operating Temperature -40°C To +85°C
Storage Temperature -40°C To +85°C
Notes:
1. Forward Voltage: +/-0.1V.
2: Measurement Tolerance Of The Chromaticity Coordinates Is ±0.01.
Symbol Parameter Device Typ. Max. Units Test Conditions
VF [1] Forward Voltage White 3.3 4.0 V IF=20mA
IR Reverse Current White 10 uA
VR = 5V
X [2]
Chromaticity Coordinates
0.31
Y [2] 0.31
C Capacitance White 100 pF VF=0V;f=1MHz
White
