Data Sheet

1. SPECIFICATION
Model
32KMNTSC
32KMPAL
Imagedevice
1/3″PIXELCMOS
SENSORPC1089K
TVType
NTSC
PAL
EffectivePixels
728(H)x488(V)380K
CellSize
6.35㎛(H)x7.40㎛(V)
HorizontalResolution
Morethan520TVLines
Sync.Type
Internal
ScanningSystem
2:1Interlace2:1Interlace
ScanningSystem
15.735KHz
ScanningFrequency(H)
15.625KHz
ScanningFrequency(V)
60Hz
50Hz
VideoOutput
1.0vppComposite(75Ω)
GammaCorrection
0.45typ.
Sensitivity
0.2Lux@F2.0
S/NRatio
Morethan42Db(AGC
OFF)
GainControlGain
Control
AutomaticAutomatic
ElectronicShutter
1/60~1/100,000secAuto
1/50~1/100,000secAuto
PowerSupply
RegulatedDC12.0V(6V~
20V)
ConsumptionCurrent
Max50mA
ReversePolarity
Yes
LensMount
FixedLensMount
OperationTemp
1050℃(Hidit10％RH
60％RH)10~50℃
(Humidity:10％RH~60％
RH)
OperationTemp
20~70℃(Humidity:10％
RH~60％RH)
PreservationTemp
32mm(H)x32mm(W)
Dimensions
Weight
Approx.26g
LensOptions
Board
Pinhole
Varifocal
f=3.6(Standard)/2.2/2.9/
