DDR3 SODIMM Product Datasheet 廣 穎 電 通 股 份 有 限 公 司 Silicon Power Computer & Communications Inc. TEL: 886-2 8797-8833 FAX: 886-2 8751-6595 台北市114內湖區洲子街106號7樓 7F, No.106, ZHO-Z ST. NEIHU DIST, 114, TAIPEI, TAIWAN, R.O.
DDR3 SODIMM Product Datasheet Index Index...................................................................................................................................................................... 2 Revision History ................................................................................................................................................ 3 Description .............................................................................................................................
DDR3 SODIMM Product Datasheet Revision History Revision No. 1.0 1.1 1.2 1.3 1.4 1.5 1.5a Date 2009/08/25 2010/4/22 2011/01/19 2011/08 2011/12 2012/5 2012/5 Remarks First release Add DDR3-1600H Add 512Mx8 type Update 512Mx8 Dual Channel Package. 3 Rev. 1.5a Nov.
DDR3 SODIMM Product Datasheet Description The Silicon Power Computer & Communications STU series products are 200-Pin Double Data Rate 3 (DDR3) Synchronous DRAM Small Outline Dual In-Line Memory Module (SODIMM), organized as a one rank 128Mx64 or 256Mx64, high-speed memory array or two ranks 128Mx64, 256Mx64, 512Mx64 high-speed memory array, The module uses four 128x16(1GB), eight 64Mx16(1GB), 128Mx8 (1GB), 128Mx16(2GB), 256Mx8 (2GB), 512Mx8 (4GB), sixteen 128Mx8 (2GB), 256Mx8 (4GB), 512Mx8 (8GB) DDR3 SDRA
DDR3 SODIMM Product Datasheet Features • DDR3 functionality and operations supported as defined in the component data sheet • 204pin, small-outline dual in-line memory module (SODIMM) • Fast data transfer rates: PC3-8500, PC3-10600,PC3-12800 • Single or Dual rank • 1GB(128 Meg x 8), 2GB (256 Meg x 64), 4GB (512Meg x 64), 8GB (1Giga x 64) • VDD = VDDQ = 1.5V ±0.075V • VDDSPD = 3.0V to 3.
DDR3 SODIMM Product Datasheet Module Specification Part Number SP001GBSTU106S01(2) SP001GBSTU133S01(2) SP001GBSTU106T01(2) SP001GBSTU133T01(2) SP001GBSTU106Q01(2) SP001GBSTU133Q01(2) SP002GBSTU106V01(2) SP002GBSTU133V01(2) SP002GBSTU160V01(2) SP002GBSTU106S01(2) SP002GBSTU133S01(2) SP002GBSTU160S01(2) SP002GBSTU106T01(2) SP002GBSTU133T01(2) SP004GBSTU106V01(2) SP004GBSTU133V01(2) SP004GBSTU160V01(2) SP004GBSTU133N01(2) SP004GBSTU160N01(2) SP008GBSTU133N01(2) SP008GBSTU160N01(2) Module Density & Configurat
DDR3 SODIMM Product Datasheet Pin Assignments 204-Pin DDR3 SODIMM Front 204-Pin DDR3 SODIMM Back Pin Symbol Pin Symbol Pin Symbol Pin Symbol Pin Symbol Pin Symbol Pin Symbol Pin Symbol 1 VREFDQ 53 DQ19 105 VDD 157 DQ42 2 VSS 54 VSS 106 VDD 158 DQ46 3 VSS 55 VSS 107 A10 159 DQ43 4 DQ4 56 DQ28 108 BA1 160 DQ47 5 DQ0 57 DQ24 109 BA0 161 VSS 6 DQ5 58 DQ29 110 RAS# 162 VSS 7 DQ1 59 DQ25 111 VDD 163 DQ48 8 VSS 60 VSS 112 VDD 164 DQ5
DDR3 SODIMM Product Datasheet Pin Description Symbol Type A0–A15 Input BA0–BA2 Input Description Address inputs: Provide the row address for ACTIVE commands and the column address and auto precharge bit for READ/WRITE commands to select one location out of the memory array in the respective bank. A10 is sampled during a PRECHARGE command to determine whether the PRECHARGE applies to one bank (A10 LOW) or all banks (A10 HIGH). If only one bank is to be precharged, the bank is selected by BA.
DDR3 SODIMM Product Datasheet Environmental Requirements Symbol Rating Units Note Module Operating Temperature Range (ambient) 0 to 55 °C 3 OPR Operating Humidity (relative) 10 to 90 % 1 STG Storage Temperature (Plastic) -55 to 100 °C 1 5 to 95 % 1 105 to 69 K Pascal 1, 2 T OPR H T H Parameter STG Storage Humidity (without condensation) BAR Barometric Pressure (operating & storage) P Note: 1. Stresses greater than those listed may cause permanent damage to the device.
DDR3 SODIMM Product Datasheet Operating temperature Conditions Symbol Parameter T OPER Rating Normal Operating Temperature Range 0 to 85 Extended Temperature Range (Optional) 85 to 95 Units Note °C 1, 2 °C 1,3 Note: 1. Operating Temperature T OPER is the case surface temperature on the center / top side of the DRAM. 2. The Normal Temperature Range specifies the temperatures where all DRAM specifications will be supported.
DDR3 SODIMM Product Datasheet Single-Ended AC and DC Input Levels for Command and Address Symbol Parameter DDR3-1066 DDR3-1333 Min. Max. Min. Max. Units Note VIH.CA(DC) DC Input Logic High Vref + 0.100 VDD Vref + 0.100 VDD V 1 VIL.CA(DC) DC Input Logic Low VSS Vref - 0.100 VSS Vref - 0.100 V 1 VIH.CA(AC) AC Input Logic High Vref + 0.175 Note 2 Vref + 0.175 Note 2 V 1, 2 VIL.CA(AC) AC Input Logic Low Note 2 Vref - 0.175 Note 2 Vref - 0.175 V 1, 2 VIH.
DDR3 SODIMM Product Datasheet Block Diagram(x8 1Rank) Note: The ZQ ball on each DDR3 component is connected to an external 240Ω resistor that is tied to ground. It is used for the calibration of the component’s ODT and output driver. 12 Rev. 1.5a Nov.
DDR3 SODIMM Product Datasheet Block Diagram(x16 1Rank) Note: The ZQ ball on each DDR3 component is connected to an external 240Ω resistor that is tied to ground. It is used for the calibration of the component’s ODT and output driver. 13 Rev. 1.5a Nov.
DDR3 SODIMM Product Datasheet Block Diagram(x8 2Ranks) Note: The ZQ ball on each DDR3 component is connected to an external 240Ω resistor that is tied to ground. It is used for the calibration of the component’s ODT and output driver. 14 Rev. 1.5a Nov.
DDR3 SODIMM Product Datasheet Block Diagram(x16 2Ranks) Note: The ZQ ball on each DDR3 component is connected to an external 240Ω resistor that is tied to ground. It is used for the calibration of the component’s ODT and output driver. 15 Rev. 1.5a Nov.
DDR3 SODIMM Product Datasheet Simplified Mechanical Drawing(x8 1Rank) Note: 1. All dimensions are in millimeters (inches); MAX/MIN or typical (TYP) where noted. Note: 2. The dimensional diagram is for reference only. 16 Rev. 1.5a Nov.
DDR3 SODIMM Product Datasheet Simplified Mechanical Drawing(x16 1Rank) Note: 1. All dimensions are in millimeters (inches); MAX/MIN or typical (TYP) where noted. Note: 2. The dimensional diagram is for reference only. 17 Rev. 1.5a Nov.
DDR3 SODIMM Product Datasheet Simplified Mechanical Drawing(x8 2Ranks) Note 1: All dimensions are in millimeters (inches); MAX/MIN or typical (TYP) where noted. Note 2: The dimensional diagram is for reference only. 18 Rev. 1.5a Nov.
DDR3 SODIMM Product Datasheet Simplified Mechanical Drawing(x16 2Ranks) Note 1: All dimensions are in millimeters (inches); MAX/MIN or typical (TYP) where noted. Note 2: The dimensional diagram is for reference only. 19 Rev. 1.5a Nov.
