Refrigerated Base Remote Condenser Spec Sheet

1100 Old Honeycutt Road, Fuquay-Varina, NC 27526
[phone] www.southbendnc.com
Models:
www.yatesgd.com www.yatesgraphicdesign.com
Power cord and condensate drain tube
located behind left sidepanel.
Tubing Cover for 60” and larger units.
INTENDED FOR COMMERCIAL USE ONLY.
NOT FOR HOUSEHOLD USE.
MISCELLANEOUS
UTILITY INFORMATION
- If casters are used with ex hose, a restraining
device should be used to eliminate undue strain on
the ex hose.
- Minimum clearance on rear is 2” (51 mm)
- Modular range top sections can be mounted
directly on top using an insulated base adapter.
- Can be part of sectional battery, provided that
the adjoining base sections are insulated, or do not
produce heat.
- Avoid locating where the temperature will drop
below 55°F or rise above 90°F
- Check local codes for fire and sanitary
regulations.
NOTICE:
Southbend has a policy of continuous product
research and improvement. We reserve the
right to change specications and product design
without notice. Such revisions do not entitle the
buyer to corresponding changes, improvements,
additions or replacements for previously purchased
equipment.
All models have a six foot power cord with a grounded plug to receive 50Hz or 60Hz
single-phase AC. Condensate drain is a 1/2” inside diameter vinyl tube. Condenser
unit is NOT included.
Form PRR Rev 6 (August/2014)
OPTIONS AND ACCESSORIES
The drawer-front width, drawer-extension distance, and overall depth may vary (the maximum values are specied and shown)
 Cable restraint kit (to restrict movement when on casters)
 Casters -front two casters lock
 Open-frame base with casters
Model Width
# of
Drawers
# of
Pans
Cooled
Volume
cu. ft (cu. m.)
Cooling Cap
BTU/hour
Electricity
120V Amps
Compressor
Motor
Shipping
Weight
18” 26” 31”
20032RSB 32” - 2 - 4 7.3 (0.21) 1550 2.5 1/4 H.P.
325 lbs
(147 kg)
20036RSB 36” - 2 - 4 7.3 (0.21) 1550 2.5 1/4 H.P.
325 lbs
(147 kg)
20048RSB 48” - - 2 4 10 (0.28) 1775 2.5 1/4 H.P.
400 lbs
(181 kg)
20060RSB 60” 2 2 - 6 13 (0.28) 1875 3 1/4 H.P.
530 lbs
(240 kg)
20064RSB 64” 2 2 - 6 13 (0.28) 1875 3 1/4 H.P.
530 lbs
(240 kg)
20072RSB 72” - 2 2 8 16 (0.45) 1920 3 1/3 H.P.
637 lbs
(289 kg)
20084RSB 84” 4 2 - 8 19 (0.54) 1955 7 1/3 H.P.
735 lbs
(333 kg)
20096RSB 96” - 6 - 12 23 (0.51) 1955 4 1/2 H.P.
835 lbs
(379 kg)
20108RSB 108” - 2 4 12 26 (0.74) 2000 4 1/2 H.P.
940 lbs
(426 kg)
Amperage is approximate and is for compressor only. Do not use for breaker sizing.
