XL-PowerStation
TheXL-PowerStationisanoptionalaccessoryfortheA20-MINIoeringbatterycharging,timecodejamming,andUSBletransferto
and from a computer for up to eight A20-MINI transmitters.
1
1
2
2
3
3
4
4
A A
B B
MATERIAL
TITLE
XL-PowerStation Public
SIZE
B
SHEET 1 OF 1
Tolerance unless
otherwise specified:
.XXX +/- .005"
.XX +/- .010"
.X +/- .030"
Angles +/- .5

ENG
Spencer
DATE
1/18/2021
E7556 State Road 23/33
Reedsburg, WI 53959
.
DWG #
Dimensions are in inches unless
otherwise specified.
DEVICES SOUND
PH: 608-524-0625
FAX: [phone]
CONFIDENTIAL AND PROPRIETARY TO SOUND DEVICES LLC.
NOT TO BE DISCLOSED OR DISTRIBUTED WITHOUT CONSENT.
www.sounddevices.com
1
1
2
2
3
3
4
4
A A
B B
MATERIAL
TITLE
XL-PowerStation Public
SIZE
B
SHEET 1 OF 1
Tolerance unless
otherwise specified:
.XXX +/- .005"
.XX +/- .010"
.X +/- .030"
Angles +/- .5

ENG
Spencer
DATE
1/18/2021
E7556 State Road 23/33
Reedsburg, WI 53959
.
DWG #
Dimensions are in inches unless
otherwise specified.
DEVICES SOUND
PH: 608-524-0625
FAX: [phone]
CONFIDENTIAL AND PROPRIETARY TO SOUND DEVICES LLC.
NOT TO BE DISCLOSED OR DISTRIBUTED WITHOUT CONSENT.
www.sounddevices.com
Charging Bay
BNC LTC Input
USB-C for-
File Transfer
File Transfer
Status LED
USB-PD
Power Input
TA-4 10-18 Volt DC
Input
Charging Batteries with the XL-PowerStation
Enabled charging bays are indicated by LEDs within each
charging bay. If the TA-4 or USB-PD with proper rating is used,
all eight charging bay LEDs illuminate. If a USB-PD adapter is
used which does not supply enough power, then only three of
the charging bay LEDs will illuminate.
The XL-PowerStation charges Sony NP-BX1 battery within an
A20-MINI. AAA battery charging is not supported. Inserting
A20-MINIs with AAA batteries into the charging bay will not
damage anything, but the unit will simply not charge.
Insert the A20-MINI into an enabled charging bay of the
XL-PowerStation. The A20-MINI slides into a charging bay with
theantenna-siderst,theantennamaybeleftattached.Sound
Devices recommends disconnecting lavalier microphones be-
fore inserting the A20-MINI into the charging bay.
Charging status is indicated by the SD-Remote application and
the A20-MINI bottom panel Charge LED.
• Solid Yellow = Charging
• Solid Green = Charging complete
• O=Notcharging
A20-MINItransmittersareautomaticallypoweredowhenin-
serted into a charging bay. The A20-MINI automatically powers
on when removed from the charging bay if ‘Power On When
Removed from XL-PowerStation’ is enabled.
Bottom Panel 1/4”-20 Mounting Point (not pictured)
TheXL-PowerStationoersa1/4”-20mountingpointonthe
bottom panel for securely attaching to a rack shelf.
Powering the XL-PowerStation
The XL-PowerStation is powered via 12 VDC TA-4 connector
or USB-PD power supply. If not powering via the TA-4, use
the supplied 36 W USB-PD power supply. If wanting to use a
dierentUSB-PDpowersupply,makesureitisratedat36Wor
higher in order to charge all eight A20-MINIs at a time.
